008 Circulator Pump, 1/25 HP, 115V

Description

Cast Iron Taco 008-F6 Circulator Pump is specially designed for use in higher-head applications, such as hydronic heating, radiant heating and solar heating. A typical application for the Taco 008 circulator is in conjunction with a radiant heat manifold in mixing stations and radiant panels. This model features a unique, field-serviceable cartridge that contains all moving parts. Taco 008-F6 Circulator Pump is compact, direct-drive, has low power consumption and is ideal for high-efficiency jobs.

Applications:

• Hydronic Heating/Cooling
• Radiant Heating
• Zoning with Pumps
• Mixing Stations
• Hydro-Air Fan Coils
• And others

Cross-References:

• Grundfos UP15-42F/R, UPS15-58FC spd 2
• Armstrong Astro30
• Wilo Star 16

Technical Specifications:

• Flow Range: 0 – 14 GPM;
• Head Range: 0 – 16 Feet;
• Minimum Fluid Temperature: 40˚F (4˚C);
• Maximum Fluid Temperature: 240°F (115˚C);
• Maximum Working Pressure: 125 psi;
• Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged;
• Voltage: 115V;
• Hertz: 60Hz;
• Phase: 1;
• Amps: 0.79A;
• HP: 1/25HP;

Warranty:
3-year manufacturer’s warranty.
